Bynav X1-6 vs eSurvey E800
What X1-6 does better (3) and where E800 wins (0) — every spec side by side.
Dimensions
Size comparison
X1-6E800
| X1-6 | E800 | Difference | |
|---|---|---|---|
| Height | 116 mm | 76 mm | +40 mm |
| Width | 114 mm | 154 mm | −40 mm |
| Depth | 39 mm | 154 mm | −115 mm |
| Weight | 432 g | 1,500 g | −1,068 g |
Drawn to the same scale from the official dimensions (front and side).
Why is X1-6 better than E800?
- Weight432 g vs 1,500 g3.5×
- Multi-band GNSS (L1 + L5/L2)Yes · E800: No
- Operating temperature (max)85 °C vs 65 °C+31%
Why is E800 better than X1-6?
E800 has no measurable advantages in this pair.
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | 6 | 6 |
| Multi-band GNSS (L1 + L5/L2) | Yes | No |
| Frequency bands | L1, L2, L5, E1, E5b, B1, B2 | L-band |
| Tracking channels | — | 800 |
| SBAS (WAAS / EGNOS) | — | Yes |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | — | 8 mm |
| Static accuracy (horizontal) | — | 2 mm |
| Tilt compensation (IMU) | Yes | — |
| Correction sources | — | NTRIP (internet), UHF radio, Cellular modem, L-band / PPP, SBAS |
| Built-in UHF radio | — | Yes |
| L-band / PPP corrections | — | Yes |
| Maps & navigation | ||
| Internal storage | — | 32 GB |
| Connectivity & safety | ||
| Bluetooth | Yes | Yes |
| Cellular modem (4G / LTE) | — | Yes |
| USB-C | — | Yes |
| Battery & power | ||
| Battery life | — | 15 h |
| Battery capacity | — | 13,600 mAh |
| External power input | — | 5-pin lemo, 9~28 VDC |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| Drop resistance | — | 2 m |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 85 °C | 65 °C |
| Weight | 432 g | 1,500 g |
| Width | 114 mm | 154 mm |
| Height | 116 mm | 76 mm |
| Depth | 39 mm | 154 mm |
| Housing material | aluminium | Magnesium Alloy |
