Bynav M20 vs JAVAD TRIUMPH-3NR
What M20 does better (2) and where TRIUMPH-3NR wins (0) — every spec side by side.
4.0Positioning3.3
Dimensions
Size comparison
M20TRIUMPH-3NR
| M20 | TRIUMPH-3NR | Difference | |
|---|---|---|---|
| Height | 17 mm | 61 mm | −44 mm |
| Width | 22 mm | 132 mm | −110 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is M20 better than TRIUMPH-3NR?
- Tracking channels1,507 vs 874+72%
- Operating temperature (max)85 °C vs 60 °C+42%
Why is TRIUMPH-3NR better than M20?
TRIUMPH-3NR has no measurable advantages in this pair.
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | 6 | 6 |
| Multi-band GNSS (L1 + L5/L2) | — | No |
| Frequency bands | — | L-band |
| Tracking channels | 1,507 | 874 |
| SBAS (WAAS / EGNOS) | Yes | — |
| RTK positioning | Yes | — |
| RTK accuracy (horizontal) | 10 mm | — |
| Tilt compensation (IMU) | Yes | Yes |
| Dual-antenna heading | Yes | — |
| Correction sources | L-band / PPP, SBAS | — |
| L-band / PPP corrections | Yes | — |
| Maps & navigation | ||
| Internal storage | — | 31 GB |
| Connectivity & safety | ||
| Wi-Fi | — | Yes |
| Bluetooth | — | Yes |
| Battery & power | ||
| Battery life | — | 25 h |
| External power input | 5V; 3.3V | 10-30 VDC |
| Build & durability | ||
| Protection rating | — | IP68 |
| Water protection (IPx) | — | IPx8 |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 85 °C | 60 °C |
| Weight | — | 630 g |
| Width | 22 mm | 132 mm |
| Height | 17 mm | 61 mm |
| Depth | — | 85 mm |
| Housing material | Aluminium | Hardened Plastic |
