ComNav M300 Plus vs eSurvey E800
What M300 Plus does better (2) and where E800 wins (5) — every spec side by side.
Dimensions
Size comparison
M300 PlusE800
| M300 Plus | E800 | Difference | |
|---|---|---|---|
| Height | 67 mm | 76 mm | −9 mm |
| Width | 176 mm | 154 mm | +22 mm |
| Depth | 225 mm | 154 mm | +71 mm |
| Weight | 2,000 g | 1,500 g | +500 g |
Drawn to the same scale from the official dimensions (front and side).
Why is M300 Plus better than E800?
- Multi-band GNSS (L1 + L5/L2)Yes · E800: No
- Operating temperature (max)80 °C vs 65 °C+23%
Why is E800 better than M300 Plus?
- Satellite systems supported4 vs 6+50%
- Weight2,000 g vs 1,500 g+33%
- Drop resistance1 m vs 2 m2×
- Tracking channels574 vs 800+39%
- Static accuracy (horizontal)2.5 mm vs 2 mm+25%
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | 4 | 6 |
| Multi-band GNSS (L1 + L5/L2) | Yes | No |
| Frequency bands | L1, L2, L5, E1, E5a, E5b, B1, B2, B3 | L-band |
| Tracking channels | 574 | 800 |
| SBAS (WAAS / EGNOS) | Yes | Yes |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | 8 mm | 8 mm |
| Static accuracy (horizontal) | 2.5 mm | 2 mm |
| Correction sources | NTRIP (internet), Cellular modem, L-band / PPP, SBAS | NTRIP (internet), UHF radio, Cellular modem, L-band / PPP, SBAS |
| Built-in UHF radio | — | Yes |
| L-band / PPP corrections | Yes | Yes |
| Raw data logging (RINEX) | Yes | — |
| Maps & navigation | ||
| Internal storage | 32 GB | 32 GB |
| Connectivity & safety | ||
| Bluetooth | — | Yes |
| Cellular modem (4G / LTE) | Yes | Yes |
| USB-C | — | Yes |
| Battery & power | ||
| Battery life | — | 15 h |
| Battery capacity | — | 13,600 mAh |
| External power input | — | 5-pin lemo, 9~28 VDC |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| Drop resistance | 1 m | 2 m |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 80 °C | 65 °C |
| Weight | 2,000 g | 1,500 g |
| Width | 176 mm | 154 mm |
| Height | 67 mm | 76 mm |
| Depth | 225 mm | 154 mm |
| Housing material | Magnesium-aluminium | Magnesium Alloy |
