ComNavGNSS / RTK receiver
ComNav Z30 Portable
ComNav Z30 Portable is a GNSS / RTK receiver released in 2023. Key specs: RTK accuracy (horizontal) 8 mm, tracking channels 965, satellite systems supported 6, multi-band GNSS (L1 + L5/L2).
4.1Score
Positioning8.5
Connectivity & safety5.9
Battery3.5
Durability2.4
price range—
- Year
- 2023
- Brand
- ComNav
- Popularity
- #145 of 301
- Model numbers
- Z30 Portable GNSS Receiver
8 mmRTK accuracy (horizontal)
965Tracking channels
6Satellite systems supported
YesMulti-band GNSS (L1 + L5/L2)
10 hBattery life
IPx5Water protection (IPx)
185 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
RTK accuracy (horizontal) · 8 mmTop 47%
Tracking channels · 965Bottom 42%
Satellite systems supported · 6Top 22%
Battery life · 10 hBottom 40%
Water protection (IPx) · IPx5Bottom 3%
Weight · 185 gTop 18%
Compared with every model of this kind in the catalog.
compared with other GNSS / RTK receivers
Why is Z30 Portable a good choice?
Weight: 185 gbetter than 96% of GNSS / RTK receivers
Satellite systems supported: 6better than 70% of GNSS / RTK receivers
Weak points
Water protection (IPx): IPx5worse than 100% of GNSS / RTK receivers
Battery life: 10 hworse than 84% of GNSS / RTK receivers
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 6
- Multi-band GNSS (L1 + L5/L2)
- Yes
- Frequency bands
- L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3
- Tracking channels
- 965
- SBAS (WAAS / EGNOS)
- Yes
- RTK positioning
- Yes
- RTK accuracy (horizontal)
- 8 mm
Connectivity & safety
- Bluetooth
- Yes
- Cellular modem (4G / LTE)
- Yes
- USB-C
- Yes
Battery & power
- Battery life
- 10 h
- Battery capacity
- 5,000 mAh
Build & durability
- Protection rating
- IP65
- Water protection (IPx)
- IPx5
- Drop resistance
- 1 m
- Operating temperature (min)
- -20 °C
- Operating temperature (max)
- 60 °C
- Weight
- 185 g
- Housing material
- Aluminum-magnesium alloy
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
