CHCNAV CGI-230 vs SingularXYZ X1 Pro
What CGI-230 does better (2) and where X1 Pro wins (0) — every spec side by side.
Dimensions
Size comparison
CGI-230X1 Pro
| CGI-230 | X1 Pro | Difference | |
|---|---|---|---|
| Height | 350 mm | 67 mm | +283 mm |
| Width | 105 mm | 133 mm | −28 mm |
| Depth | 154 mm | 133 mm | +21 mm |
| Weight | 400 g | 870 g | −470 g |
Drawn to the same scale from the official dimensions (front and side).
Why is CGI-230 better than X1 Pro?
- Weight400 g vs 870 g2.2×
- Operating temperature (max)75 °C vs 65 °C+15%
Why is X1 Pro better than CGI-230?
X1 Pro has no measurable advantages in this pair.
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | — | GPS, GLONASS, Galileo, BeiDou, QZSS |
| Satellite systems supported | — | 5 |
| Multi-band GNSS (L1 + L5/L2) | — | Yes |
| Frequency bands | — | L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3 |
| Tracking channels | — | 1,408 |
| SBAS (WAAS / EGNOS) | — | Yes |
| RTK positioning | — | Yes |
| RTK accuracy (horizontal) | — | 8 mm |
| Static accuracy (horizontal) | — | 2.5 mm |
| Tilt compensation (IMU) | Yes | Yes |
| Max. tilt angle | — | 60° |
| Dual-antenna heading | Yes | — |
| Correction sources | — | NTRIP (internet), UHF radio, Cellular modem, L-band / PPP, SBAS |
| Built-in UHF radio | — | Yes |
| L-band / PPP corrections | — | Yes |
| Raw data logging (RINEX) | — | Yes |
| Maps & navigation | ||
| Internal storage | — | 8 GB |
| Connectivity & safety | ||
| Wi-Fi | — | Yes |
| Bluetooth | — | Yes |
| Cellular modem (4G / LTE) | — | Yes |
| USB-C | — | Yes |
| Battery & power | ||
| Battery life | — | 20 h |
| External power input | — | DC 9~28V |
| Build & durability | ||
| Protection rating | — | IP68 |
| Water protection (IPx) | — | IPx8 |
| Drop resistance | — | 2 m |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 75 °C | 65 °C |
| Weight | 400 g | 870 g |
| Width | 105 mm | 133 mm |
| Height | 350 mm | 67 mm |
| Depth | 154 mm | 133 mm |
| Housing material | — | Magnesium-aluminum alloy |
