CHCNAV CGI-830 vs SingularXYZ Orion ONE
What CGI-830 does better (1) and where Orion ONE wins (1) — every spec side by side.
Dimensions
Size comparison
CGI-830Orion ONE
| CGI-830 | Orion ONE | Difference | |
|---|---|---|---|
| Height | 53 mm | 59 mm | −6 mm |
| Width | 120 mm | 107 mm | +13 mm |
| Depth | 162 mm | 107 mm | +55 mm |
| Weight | 1,150 g | 547 g | +603 g |
Drawn to the same scale from the official dimensions (front and side).
Why is CGI-830 better than Orion ONE?
- Operating temperature (max)75 °C vs 65 °C+15%
Why is Orion ONE better than CGI-830?
- Weight1,150 g vs 547 g2.1×
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | — | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | — | 6 |
| Multi-band GNSS (L1 + L5/L2) | — | Yes |
| Frequency bands | — | L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3 |
| Tracking channels | — | 1,408 |
| SBAS (WAAS / EGNOS) | — | Yes |
| RTK positioning | — | Yes |
| RTK accuracy (horizontal) | — | 8 mm |
| RTK accuracy (vertical) | — | 15 mm |
| Static accuracy (horizontal) | — | 2.5 mm |
| Tilt compensation (IMU) | Yes | Yes |
| Max. tilt angle | — | 60° |
| Correction sources | NTRIP (internet), Cellular modem | NTRIP (internet), UHF radio, LoRa radio, L-band / PPP, SBAS |
| Built-in UHF radio | — | Yes |
| L-band / PPP corrections | — | Yes |
| Raw data logging (RINEX) | — | Yes |
| Maps & navigation | ||
| Internal storage | — | 8 GB |
| Connectivity & safety | ||
| Wi-Fi | Yes | Yes |
| Bluetooth | — | Yes |
| Cellular modem (4G / LTE) | Yes | — |
| NFC | — | Yes |
| USB-C | — | Yes |
| Camera | — | Yes |
| Battery & power | ||
| Battery life | — | 12 h |
| External power input | 9 V ~ 32 V DC Standard Adaptation 12 V DC | 18V |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| MIL-STD-810 | Yes | — |
| Drop resistance | — | 2 m |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 75 °C | 65 °C |
| Weight | 1,150 g | 547 g |
| Width | 120 mm | 107 mm |
| Height | 53 mm | 59 mm |
| Depth | 162 mm | 107 mm |
| Housing material | — | Magnesium-aluminum alloy |
