BynavGNSS / RTK receiver
Bynav X8-M1
Bynav X8-M1 is a GNSS / RTK receiver released in 2024. Key specs: RTK accuracy (horizontal) 10 mm, tracking channels 1,500, satellite systems supported 6, multi-band GNSS (L1 + L5/L2).
7.0Score
Positioning4.4
Connectivity & safety5.9
Battery6.2
Durability6.4
price range—
- Year
- 2024
- Brand
- Bynav
- Popularity
- #125 of 301
- Model numbers
- Bynav X8-M1
10 mmRTK accuracy (horizontal)
1,500Tracking channels
6Satellite systems supported
YesMulti-band GNSS (L1 + L5/L2)
16 hBattery life
IPx7Water protection (IPx)
104 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
RTK accuracy (horizontal) · 10 mmBottom 8%
Tracking channels · 1,500Top 9%
Satellite systems supported · 6Top 16%
Battery life · 16 hTop 31%
Water protection (IPx) · IPx7Bottom 43%
Weight · 104 gTop 8%
Compared with every model of this kind in the catalog.
compared with other GNSS / RTK receivers
Why is X8-M1 a good choice?
Weight: 104 gbetter than 98% of GNSS / RTK receivers
Battery life: 16 hbetter than 72% of GNSS / RTK receivers
Tracking channels: 1,500better than 91% of GNSS / RTK receivers
Satellite systems supported: 6better than 70% of GNSS / RTK receivers
Weak points
Water protection (IPx): IPx7worse than 93% of GNSS / RTK receivers
RTK accuracy (horizontal): 10 mmworse than 86% of GNSS / RTK receivers
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 6
- Multi-band GNSS (L1 + L5/L2)
- Yes
- Frequency bands
- L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3
- Tracking channels
- 1,500
- SBAS (WAAS / EGNOS)
- Yes
- RTK positioning
- Yes
- RTK accuracy (horizontal)
- 10 mm
- RTK accuracy (vertical)
- 15 mm
Connectivity & safety
- Bluetooth
- Yes
- Cellular modem (4G / LTE)
- Yes
- USB-C
- Yes
Battery & power
- Battery life
- 16 h
- Battery capacity
- 3,300 mAh
- External power input
- USB Type-C (5V/1A input)
Build & durability
- Protection rating
- IP67
- Water protection (IPx)
- IPx7
- Drop resistance
- 1.5 m
- Operating temperature (min)
- -20 °C
- Operating temperature (max)
- 70 °C
- Weight
- 104 g
- Width
- 33 mm
- Height
- 133 mm
- Depth
- 30 mm
- Housing material
- ABS flame-retardant plastic
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
