eSurvey E500 vs SatLab Freyja
What E500 does better (2) and where Freyja wins (3) — every spec side by side.
Dimensions
Size comparison
E500Freyja
| E500 | Freyja | Difference | |
|---|---|---|---|
| Height | 74 mm | 67 mm | +7 mm |
| Width | 148 mm | 132 mm | +16 mm |
| Weight | 1,060 g | 800 g | +260 g |
Drawn to the same scale from the official dimensions (front and side).
Why is E500 better than Freyja?
- Operating temperature (min)-40 °C vs -30 °C+-25%
- Static accuracy (horizontal)2 mm vs 2.5 mm+25%
Why is Freyja better than E500?
- Multi-band GNSS (L1 + L5/L2)No · E500: Yes
- Weight1,060 g vs 800 g+32%
- Operating temperature (max)65 °C vs 70 °C+8%
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | 6 | 6 |
| Multi-band GNSS (L1 + L5/L2) | No | Yes |
| Frequency bands | L-band | L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3 |
| Tracking channels | 800 | 800 |
| SBAS (WAAS / EGNOS) | Yes | Yes |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | 8 mm | 8 mm |
| Static accuracy (horizontal) | 2 mm | 2.5 mm |
| Tilt compensation (IMU) | — | Yes |
| Max. tilt angle | — | 30° |
| Correction sources | NTRIP (internet), UHF radio, Cellular modem, L-band / PPP, SBAS | UHF radio, L-band / PPP, SBAS |
| Built-in UHF radio | Yes | Yes |
| L-band / PPP corrections | Yes | Yes |
| Raw data logging (RINEX) | Yes | — |
| Maps & navigation | ||
| Internal storage | 8 GB | 8 GB |
| Connectivity & safety | ||
| Bluetooth | Yes | Yes |
| Cellular modem (4G / LTE) | Yes | — |
| USB-C | Yes | — |
| Battery & power | ||
| Battery life | 12 h | 12 h |
| Battery capacity | 4,800 mAh | — |
| External power input | 5-pin lemo, 9~28 VDC | — |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| Drop resistance | 2 m | — |
| Operating temperature (min) | -40 °C | -30 °C |
| Operating temperature (max) | 65 °C | 70 °C |
| Weight | 1,060 g | 800 g |
| Width | 148 mm | 132 mm |
| Height | 74 mm | 67 mm |
| Depth | 148 mm | — |
| Housing material | Magnesium Alloy | magnesium |
