- Geode GNS3H vs SV100 INS-D
Juniper Geode GNS3H vs SingularXYZ SV100 INS-D
What Geode GNS3H does better (2) and where SV100 INS-D wins (5) — every spec side by side.
vs
2.6Positioning5.2
5.9Connectivity & safety5.9
5.4Battery5.8
8.0Durability5.3
Dimensions
Size comparison
Geode GNS3HSV100 INS-D
| Geode GNS3H | SV100 INS-D | Difference | |
|---|---|---|---|
| Height | 57 mm | 65 mm | −8 mm |
| Width | 110 mm | 142 mm | −32 mm |
| Depth | 110 mm | 162 mm | −52 mm |
| Weight | 405 g | 1,050 g | −645 g |
Drawn to the same scale from the official dimensions (front and side).
Why is Geode GNS3H better than SV100 INS-D?
- Weight405 g vs 1,050 g2.6×
- Water protection (IPx)IPx8 vs IPx7+14%
Why is SV100 INS-D better than Geode GNS3H?
- Satellite systems supported2 vs 52.5×
- Battery life12 h vs 13 h+8%
- Built-in UHF radioNo · Geode GNS3H: Yes
- Operating temperature (min)-20 °C vs -40 °C+-50%
- Operating temperature (max)60 °C vs 75 °C+25%
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | QZSS, NavIC (IRNSS) | GPS, GLONASS, Galileo, BeiDou, QZSS |
| Satellite systems supported | 2 | 5 |
| Multi-band GNSS (L1 + L5/L2) | Yes | Yes |
| Frequency bands | L1, L2, L5, E5a, E5b, E6, B1, B2, B3 | L1, L2, L5, E1, E5a, E5b, B1, B2, B3 |
| Tracking channels | 800 | — |
| SBAS (WAAS / EGNOS) | Yes | — |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | 8 mm | 8 mm |
| RTK accuracy (vertical) | 15 mm | 15 mm |
| Static accuracy (horizontal) | — | 2.5 mm |
| Tilt compensation (IMU) | — | Yes |
| Dual-antenna heading | — | Yes |
| Correction sources | NTRIP (internet), L-band / PPP, SBAS | NTRIP (internet), UHF radio, Cellular modem |
| Built-in UHF radio | No | Yes |
| L-band / PPP corrections | Yes | — |
| Raw data logging (RINEX) | — | Yes |
| Maps & navigation | ||
| Internal storage | — | 8 GB |
| Connectivity & safety | ||
| Bluetooth | Yes | Yes |
| Cellular modem (4G / LTE) | — | Yes |
| USB-C | Yes | — |
| Battery & power | ||
| Battery life | 12 h | 13 h |
| Battery capacity | 6,000 mAh | — |
| External power input | Input Voltage: 5VDC @ 2A USB | 9 - 28 V DC |
| Build & durability | ||
| Protection rating | IP68 | IP67 |
| Water protection (IPx) | IPx8 | IPx7 |
| MIL-STD-810 | Yes | Yes |
| Operating temperature (min) | -20 °C | -40 °C |
| Operating temperature (max) | 60 °C | 75 °C |
| Weight | 405 g | 1,050 g |
| Width | 110 mm | 142 mm |
| Height | 57 mm | 65 mm |
| Depth | 110 mm | 162 mm |
| Housing material | Polymer | Aluminum alloy |
