CHCNAV CGI-610 vs ComNav M10 Mini
What CGI-610 does better (2) and where M10 Mini wins (4) — every spec side by side.
Dimensions
Size comparison
CGI-610M10 Mini
| CGI-610 | M10 Mini | Difference | |
|---|---|---|---|
| Height | 50 mm | 130 mm | −80 mm |
| Width | 120 mm | 64 mm | +56 mm |
| Depth | 160 mm | 26 mm | +134 mm |
| Weight | 1,150 g | 175 g | +975 g |
Drawn to the same scale from the official dimensions (front and side).
Why is CGI-610 better than M10 Mini?
- Operating temperature (min)-40 °C vs -20 °C+-50%
- Operating temperature (max)75 °C vs 60 °C+25%
Why is M10 Mini better than CGI-610?
- Weight1,150 g vs 175 g6.6×
- RTK accuracy (horizontal)10 mm vs 8 mm+25%
- Satellite systems supported5 vs 6+20%
- Tracking channels555 vs 956+72%
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou, QZSS | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC (IRNSS) |
| Satellite systems supported | 5 | 6 |
| Multi-band GNSS (L1 + L5/L2) | — | Yes |
| Frequency bands | — | L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3 |
| Tracking channels | 555 | 956 |
| SBAS (WAAS / EGNOS) | Yes | Yes |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | 10 mm | 8 mm |
| Static accuracy (horizontal) | 10 mm | — |
| Position update rate | 100 Hz | — |
| Tilt compensation (IMU) | Yes | — |
| Dual-antenna heading | Yes | — |
| Correction sources | NTRIP (internet), Cellular modem, SBAS | NTRIP (internet), Cellular modem, SBAS |
| Built-in UHF radio | No | — |
| L-band / PPP corrections | No | — |
| Connectivity & safety | ||
| Wi-Fi | Yes | — |
| Bluetooth | Yes | Yes |
| Cellular modem (4G / LTE) | Yes | Yes |
| Battery & power | ||
| Battery life | — | 6 h |
| Battery capacity | — | 2,600 mAh |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| MIL-STD-810 | Yes | — |
| Drop resistance | — | 1 m |
| Operating temperature (min) | -40 °C | -20 °C |
| Operating temperature (max) | 75 °C | 60 °C |
| Weight | 1,150 g | 175 g |
| Width | 120 mm | 64 mm |
| Height | 50 mm | 130 mm |
| Depth | 160 mm | 26 mm |
| Housing material | Aluminium | Aluminum-magnesium alloy |
