CHCNAVGNSS / RTK receiver
CHCNAV CGI-610
CHCNAV CGI-610 is a GNSS / RTK receiver released in 2020. Key specs: RTK accuracy (horizontal) 10 mm, tracking channels 555, tilt compensation (IMU), satellite systems supported 5.
4.1Score
Positioning2.2
Connectivity & safety5.9
Durability4.8
price range—
- Year
- 2020
- Brand
- CHCNAV
- Popularity
- #215 of 301
10 mmRTK accuracy (horizontal)
555Tracking channels
YesTilt compensation (IMU)
5Satellite systems supported
IPx7Water protection (IPx)
1,150 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
RTK accuracy (horizontal) · 10 mmBottom 8%
Tracking channels · 555Bottom 19%
Satellite systems supported · 5Top 48%
Water protection (IPx) · IPx7Bottom 43%
Weight · 1,150 gBottom 13%
Compared with every model of this kind in the catalog.
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 5
- Tracking channels
- 555
- SBAS (WAAS / EGNOS)
- Yes
- RTK positioning
- Yes
- RTK accuracy (horizontal)
- 10 mm
- Static accuracy (horizontal)
- 10 mm
- Position update rate
- 100 Hz
- Tilt compensation (IMU)
- Yes
- Dual-antenna heading
- Yes
- Built-in UHF radio
- No
- L-band / PPP corrections
- No
Connectivity & safety
- Wi-Fi
- Yes
- Bluetooth
- Yes
- Cellular modem (4G / LTE)
- Yes
Build & durability
- Protection rating
- IP67
- Water protection (IPx)
- IPx7
- MIL-STD-810
- Yes
- Operating temperature (min)
- -40 °C
- Operating temperature (max)
- 75 °C
- Weight
- 1,150 g
- Width
- 120 mm
- Height
- 50 mm
- Depth
- 160 mm
- Housing material
- Aluminium
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
