ComNavGNSS / RTK receiver
ComNav M10 Mini
ComNav M10 Mini is a GNSS / RTK receiver released in 2021. Key specs: RTK accuracy (horizontal) 8 mm, tracking channels 956, satellite systems supported 6, multi-band GNSS (L1 + L5/L2).
4.0Score
Positioning8.4
Connectivity & safety5.9
Battery2.2
Durability4.1
price range—
- Year
- 2021
- Brand
- ComNav
- Popularity
- #190 of 301
- Model numbers
- M10 Mini GNSS Receiver
8 mmRTK accuracy (horizontal)
956Tracking channels
6Satellite systems supported
YesMulti-band GNSS (L1 + L5/L2)
6 hBattery life
IPx7Water protection (IPx)
175 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
RTK accuracy (horizontal) · 8 mmTop 47%
Tracking channels · 956Bottom 40%
Satellite systems supported · 6Top 19%
Battery life · 6 hBottom 27%
Water protection (IPx) · IPx7Bottom 43%
Weight · 175 gTop 13%
Compared with every model of this kind in the catalog.
compared with other GNSS / RTK receivers
Why is M10 Mini a good choice?
Weight: 175 gbetter than 97% of GNSS / RTK receivers
Satellite systems supported: 6better than 70% of GNSS / RTK receivers
Weak points
Water protection (IPx): IPx7worse than 93% of GNSS / RTK receivers
Battery life: 6 hworse than 95% of GNSS / RTK receivers
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 6
- Multi-band GNSS (L1 + L5/L2)
- Yes
- Frequency bands
- L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3
- Tracking channels
- 956
- SBAS (WAAS / EGNOS)
- Yes
- RTK positioning
- Yes
- RTK accuracy (horizontal)
- 8 mm
Connectivity & safety
- Bluetooth
- Yes
- Cellular modem (4G / LTE)
- Yes
Battery & power
- Battery life
- 6 h
- Battery capacity
- 2,600 mAh
Build & durability
- Protection rating
- IP67
- Water protection (IPx)
- IPx7
- Drop resistance
- 1 m
- Operating temperature (min)
- -20 °C
- Operating temperature (max)
- 60 °C
- Weight
- 175 g
- Width
- 64 mm
- Height
- 130 mm
- Depth
- 26 mm
- Housing material
- Aluminum-magnesium alloy
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
