ComNav M300 Mini vs Hi-Target iRTK5
What M300 Mini does better (3) and where iRTK5 wins (0) — every spec side by side.
Dimensions
Size comparison
M300 MiniiRTK5
| M300 Mini | iRTK5 | Difference | |
|---|---|---|---|
| Height | 52 mm | 98 mm | −46 mm |
| Width | 142 mm | 158 mm | −16 mm |
| Weight | 800 g | 1,200 g | −400 g |
Drawn to the same scale from the official dimensions (front and side).
Why is M300 Mini better than iRTK5?
- Weight800 g vs 1,200 g+50%
- Satellite systems supported5 vs 4+25%
- Tracking channels496 vs 336+48%
Why is iRTK5 better than M300 Mini?
iRTK5 has no measurable advantages in this pair.
Specifications
Side by side
| Satellite positioning | ||
| Satellite systems | GPS, GLONASS, Galileo, BeiDou, QZSS | GPS, GLONASS, Galileo, BeiDou |
| Satellite systems supported | 5 | 4 |
| Multi-band GNSS (L1 + L5/L2) | — | Yes |
| Frequency bands | — | L1, L2, L5, E1, E5a, E5b, E6, B1, B2, B3 |
| Tracking channels | 496 | 336 |
| SBAS (WAAS / EGNOS) | Yes | Yes |
| RTK positioning | Yes | Yes |
| RTK accuracy (horizontal) | 8 mm | — |
| RTK accuracy (vertical) | 15 mm | — |
| Static accuracy (horizontal) | 2.5 mm | — |
| Tilt compensation (IMU) | — | Yes |
| Correction sources | NTRIP (internet), UHF radio, Cellular modem, SBAS | NTRIP (internet), UHF radio, Cellular modem, L-band / PPP, SBAS |
| Built-in UHF radio | Yes | Yes |
| L-band / PPP corrections | — | Yes |
| Raw data logging (RINEX) | — | Yes |
| Maps & navigation | ||
| Internal storage | — | 16 GB |
| Memory card slot | — | Yes |
| Connectivity & safety | ||
| Wi-Fi | — | Yes |
| Bluetooth | — | Yes |
| Cellular modem (4G / LTE) | Yes | Yes |
| Battery & power | ||
| Battery life | — | 9 h |
| Battery capacity | — | 6,800 mAh |
| External power input | — | 6-28V DC external power input（5-pin port） with over-discharge protection |
| Build & durability | ||
| Protection rating | IP67 | IP67 |
| Water protection (IPx) | IPx7 | IPx7 |
| Drop resistance | 1 m | — |
| Operating temperature (min) | -40 °C | -40 °C |
| Operating temperature (max) | 75 °C | 75 °C |
| Weight | 800 g | 1,200 g |
| Width | 142 mm | 158 mm |
| Height | 52 mm | 98 mm |
| Depth | 191 mm | — |
| Housing material | Rugged aluminum alloy | Magnesium Alloy |
