ComNavGNSS / RTK receiver
ComNav G100
ComNav G100 is a GNSS / RTK receiver released in 2017. Key specs: tracking channels 200, satellite systems supported 3, battery life 9 h, water protection (IPx) IPx5.
3.5Score
Positioning2.0
Battery2.7
Durability2.5
price range—
- Year
- 2017
- Brand
- ComNav
- Popularity
- #297 of 301
- Model numbers
- G100 GNSS Receiver
200Tracking channels
3Satellite systems supported
NoMulti-band GNSS (L1 + L5/L2)
9 hBattery life
IPx5Water protection (IPx)
350 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
Tracking channels · 200Bottom 3%
Satellite systems supported · 3Bottom 32%
Battery life · 9 hBottom 35%
Water protection (IPx) · IPx5Bottom 3%
Weight · 350 gTop 39%
Compared with every model of this kind in the catalog.
compared with other GNSS / RTK receivers
Why is G100 a good choice?
Weight: 350 gbetter than 90% of GNSS / RTK receivers
Weak points
Water protection (IPx): IPx5worse than 100% of GNSS / RTK receivers
Battery life: 9 hworse than 92% of GNSS / RTK receivers
Satellite systems supported: 3worse than 99% of GNSS / RTK receivers
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 3
- Multi-band GNSS (L1 + L5/L2)
- No
- Frequency bands
- L1, B1
- Tracking channels
- 200
- SBAS (WAAS / EGNOS)
- Yes
Connectivity & safety
- Bluetooth
- Yes
Battery & power
- Battery life
- 9 h
- Battery capacity
- 3,400 mAh
- External power input
- 5-27 VDC
Build & durability
- Protection rating
- IP65
- Water protection (IPx)
- IPx5
- Drop resistance
- 1.5 m
- Operating temperature (min)
- -20 °C
- Operating temperature (max)
- 60 °C
- Weight
- 350 g
- Width
- 72 mm
- Height
- 50 mm
- Depth
- 137 mm
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
