ComNavGNSS / RTK receiver
ComNav G200
ComNav G200 is a GNSS / RTK receiver released in 2018. Key specs: RTK accuracy (horizontal) 8 mm, tracking channels 352, satellite systems supported 4, multi-band GNSS (L1 + L5/L2).
3.6Score
Positioning2.5
Battery2.7
Durability2.5
price range—
- Year
- 2018
- Brand
- ComNav
- Popularity
- #276 of 301
- Model numbers
- G200 GNSS Receiver
8 mmRTK accuracy (horizontal)
352Tracking channels
4Satellite systems supported
YesMulti-band GNSS (L1 + L5/L2)
9 hBattery life
IPx5Water protection (IPx)
350 gWeight
Spec guide
How it ranks among GNSS / RTK receivers
RTK accuracy (horizontal) · 8 mmTop 47%
Tracking channels · 352Bottom 9%
Satellite systems supported · 4Bottom 38%
Battery life · 9 hBottom 35%
Water protection (IPx) · IPx5Bottom 3%
Weight · 350 gTop 39%
Compared with every model of this kind in the catalog.
compared with other GNSS / RTK receivers
Why is G200 a good choice?
Weight: 350 gbetter than 90% of GNSS / RTK receivers
Weak points
Water protection (IPx): IPx5worse than 100% of GNSS / RTK receivers
Battery life: 9 hworse than 92% of GNSS / RTK receivers
Satellite systems supported: 4worse than 97% of GNSS / RTK receivers
Specifications
Full specifications
Satellite positioning
- Satellite systems supported
- 4
- Multi-band GNSS (L1 + L5/L2)
- Yes
- Frequency bands
- L1, L2, E1, E5b, B1, B2
- Tracking channels
- 352
- SBAS (WAAS / EGNOS)
- Yes
- RTK positioning
- Yes
- RTK accuracy (horizontal)
- 8 mm
- Static accuracy (horizontal)
- 3 mm
Connectivity & safety
- Bluetooth
- Yes
Battery & power
- Battery life
- 9 h
- Battery capacity
- 3,400 mAh
- External power input
- 5-27 VDC
Build & durability
- Protection rating
- IP65
- Water protection (IPx)
- IPx5
- Drop resistance
- 1.5 m
- Operating temperature (min)
- -20 °C
- Operating temperature (max)
- 60 °C
- Weight
- 350 g
- Width
- 72 mm
- Height
- 50 mm
- Depth
- 137 mm
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
